ANSI/ASME B16.36 is a standard that specifically addresses flanges for orifice flange assemblies. These flanges are commonly used in various industries to measure fluid flow rates or control fluid flow through an orifice plate. The standard defines the dimensions, materials, and other specifications for orifice flanges to ensure their compatibility and reliability in industrial applications.
The ANSI/ASME B16.36 flange has multiple significant characteristics that make it perfect for its purpose. Its main features are robustness and durability, which can handle high pressures and temperatures typically seen in industries. Furthermore, these flanges are manufactured to provide a sealed and tight fit, guaranteeing the soundness of the orifice flange setup.
Another significant property of the ANSI/ASME B16.36 flange is its versatility. It can be manufactured in various sizes and pressure ratings, accommodating various applications and operating conditions. The standard provides guidelines for flange dimensions, bolt-hole patterns, and flange-facing types, ensuring interchangeability and compatibility with other components.
Furthermore, the ANSI/ASME B16.36 flange offers easy installation and maintenance. The flange's design simplifies the assembly process, enabling efficient installation and disassembly of orifice flange systems. This facilitates quick access to the orifice plate for inspection, cleaning, or replacement, minimising downtime and maintenance costs.
Regarding materials, ANSI/ASME B16.36 flanges can be constructed from various materials, including carbon steel, stainless steel, and alloy steel. The choice of material depends on the specific application requirements, such as the fluid being handled, temperature, and pressure conditions. The standard provides guidelines for material selection to ensure compatibility with the operating environment.
