304 treated steel is one of the most broadly and by and large utilized tempered steel levels. It is regardless called the 18 - 8 chromium nickel grade by the SS 304 Nut Bolt Manufacturer. Other than being versatile, type 304 set steel snares offer a moderate option instead of different treated steel. This level of secure is sensible because of the tempered steel having uncommon deterioration opposition properties towards a wide extent of general and limited harming media.
Stainless Steel 304 / 304H / 304L Fasteners, Stainless Steel 304 / 304H / 304L Fasteners Manufacturers, Stainless Steel 304 / 304H / 304L Fasteners Exporters, Stainless Steel 304 / 304H / 304L Fasteners Suppliers, Stainless Steel 304 / 304H / 304L Fasteners Stockists. SS 304 Bolts Manufacturer India, Supplies SS 304 Bolts And Nuts, 304 Stainless Steel Screws, AISI 304 Nuts, Stud Bolts, Type 304 Stainless Steel Fasteners At Factory Price In India.
Close by going against air deterioration, SS 304 Bolts And Nuts have remarkable obstruction in reasonably oxidizing and diminishing conditions. The SS 304 Bolt has uncommon confirmation from intergranular breaking down in its as welded condition. Because of the 304 Stainless Steel Nuts being palatable at confining these corruptions or corrodents, they have a long work or association life. Therefore they are not ought to have been changed at short stretches.
Stainless Steel 304 / 304H / 304L Fasteners Manufacturers in Mumbai, Stainless Steel 304 / 304H / 304L Fasteners Exporters in Mumbai, Stainless Steel 304 / 304H / 304L Fasteners Suppliers in Mumbai, Stainless Steel 304 / 304H / 304L Fasteners Stockists in Mumbai, Carries A Complete Line Of Astm A 193 Stainless Steel 304 Fasteners, SS 304 Bolt, SS 304 Hex Bolts, 304 SS Stud Bolts, S30400 Bolt, 304 Stainless Steel Nuts, Ss 304 Nuts And Bolts In Mumbai, India.
Omaa Metal Sources, Other than being seen for its use opposition properties, the SS 304 Fasteners have remarkable strength and hardness properties. In actuality the sort 304 treated steel snares, show unfathomable strength and quality at cryogenic temperatures. These properties are acquired by the SS 304 Hex Bolts due to the chromium content in the alloyWe are a great deal of obvious for being a hero among various SS 304 Fasteners Manufacturers In India.
Treated Steel 304 Bolts comes in different sorts like SS 304 Hex Bolts, SS 304 Stud Bolts, AISI 304 Flange shocks, SUS 304 Shoulder shocks, Grade 304 Anchor shocks and s30400 shock. We at Fasteners online give genuine and online cost of Grade 304 Stainless steel screws and nuts. Our cost is relevant in Qatar, UAE, Malaysia, Indonesia, Singapore, Thailand, Zambia, Azerbaijan including West african nations and Middle East nations.
Also check ss 304 nut lock cost list,ss 304 screw quality and 304 treated steel screw power diagram before you purchase the material. Our SS 304 nut bols goes with Torq Test, Tensile Test, Fatigue Test, Shear test and confirmation. The essential worry to consider SS 304 Bolts are Torque diagram, Strength, Shear Strength, Grades, Mechanical properties, Torq format metric and yield quality. That will assist with picking the right material. Additionally check our 304 hardened steel hung shaft cost per piece.
304 Stainless Steel Fasteners Specifications
| Stainless Steel 304 Fasteners Specifications | ASTM A193 / A193, ASME SA193 / SA194 |
| Standard of Stainless Steel 304 Fasteners | DIN, ASTM, BS and all International Standards |
| 304 Stainless Steel Fasteners Length | 3 mm to 200 mm |
| 304 Stainless Steel Nuts Size | M3 - M56 | 3/6" to 2" | Custom Sizes |
| SS 304 Bolt / Screw Size | M3 - M56 | 3/6" to 2" | Custom Sizes |
| 304 Stainless Steel Machine Screws Size | M1.6 - M12 |
| 304 Stainless Steel Washers Size | M3 - M56 | 3/6" to 2" | Custom Sizes |
| Stainless Steel Grades | SS 304 |
| Stainless Steel 304 Fasteners Type | Bolts, Nuts, Sockets, Screws, Screw, Studs, Socket Screw, Hex Set Screw, Cap Screw, Machine Screw, Pan Head Screw, Allen Cap screw, Socket Head Cap Screw, Wing Screw, Spring Washers, Washers, Studs, Marine Anchors, Anchors, Hexagon Nut, Nut, Hex Coupling Nut, Hex Nut, Square Nut, Hex Domed Cap Nuts, Hex Head Bolts, Stud Bolts, Socket Hexagon Head Screw,U- Bolts, Anchor Bolt, Mushroom Head Square Neck Bolts, J Bolts, Wing Screw, T-Head Bolts, Foundation Bolts, Eye Bolt,Structural Bolts. |
SS 304 Bolt Dimensions
NOMINAL SIZE (D) |
BODY DIAMETER |
HEAD THICKNEASTM A193 |
ACROASTM A193 THE FLATS |
ACROASTM A193 CORNERS |
||||
|---|---|---|---|---|---|---|---|---|
D (MAX) |
D (MIN) |
H (MAX) |
H (MIN) |
F (MAX) |
F (MIN) |
C (MAX) |
C (MIN) |
|
m10 |
10.00 |
9.78 |
6.63 |
6.17 |
17.00 |
15.73 |
18.48 |
17.77 |
m12 |
12.00 |
11.73 |
7.76 |
4.24 |
19.00 |
17.73 |
20.78 |
20.03 |
m14 |
14.00 |
13.73 |
9.09 |
8.51 |
22.00 |
20.67 |
24.25 |
23.35 |
m16 |
16.00 |
15.73 |
10.32 |
9.68 |
24.00 |
23.67 |
27.71 |
26.75 |
m20 |
20.00 |
19.67 |
12.88 |
12.12 |
30.00 |
29.16 |
34.64 |
32.95 |
m24 |
24.00 |
23.67 |
15.44 |
14.56 |
36.00 |
35.00 |
41.57 |
39.55 |
m30 |
30.00 |
29.67 |
19.48 |
17.92 |
46.00 |
45.00 |
53.12 |
50.85 |
m36 |
36.00 |
35.61 |
23.38 |
21.63 |
55.00 |
53.80 |
63.51 |
60.79 |
m42 |
42.00 |
41.38 |
26.97 |
25.03 |
65.00 |
62.90 |
75.06 |
71.71 |
m48 |
48.00 |
47.38 |
31.07 |
28.93 |
75.00 |
72.60 |
86.60 |
82.76 |
m56 |
56.00 |
55.26 |
36.2 |
33.80 |
85.00 |
82.20 |
98.15 |
93.71 |
m64 |
64.00 |
63.26 |
41.32 |
38.68 |
95.00 |
91.80 |
109.70 |
104.65 |
m72 |
72.00 |
71.26 |
46.45 |
43.55 |
105.00 |
101.40 |
121.24 |
115.60 |
m80 |
80.00 |
79.26 |
51.58 |
48.42 |
115.00 |
111.00 |
132.72 |
126.54 |
m90 |
90.00 |
89.13 |
57.74 |
54.26 |
130.00 |
125.50 |
150.11 |
143.07 |
m100 |
90.00 |
99.13 |
63.9 |
60.10 |
145.00 |
140.00 |
167.43 |
159.60 |
304L Stainless Steel Bolts Torque Chart
Torque Specifications |
|||||||
|---|---|---|---|---|---|---|---|
Bolt Size
Inches or # |
Threads
Per Inch |
Standard Dry Torque in Inch-Pounds
|
|||||
304
Stainless Steel |
316
Stainless Steel |
||||||
#2 |
56 |
2.5 |
2.6 |
||||
64 |
3.0 |
3.2 |
|||||
#3 |
48 |
3.9 |
4.0 |
||||
56 |
4.4 |
4.6 |
|||||
#4 |
40 |
5.2 |
5.5 |
||||
48 |
6.6 |
6.9 |
|||||
#5 |
40 |
7.7 |
8.1 |
||||
44 |
9.4 |
9.8 |
|||||
#6 |
32 |
9.6 |
10.1 |
||||
40 |
12.1 |
12.7 |
|||||
#8 |
32 |
19.8 |
20.7 |
||||
36 |
22.0 |
23.0 |
|||||
#10 |
24 |
22.8 |
23.8 |
||||
32 |
31.7 |
33.1 |
|||||
Bolt Size
Inches or # |
Threads
Per Inch |
Standard Dry Torque in Inch-Pounds
|
|||||
304
Stainless Steel |
316
Stainless Steel |
||||||
1/4 |
20 |
75.2 |
78.8 |
||||
28 |
94.0 |
99.0 |
|||||
5/16 |
18 |
132 |
138 |
||||
24 |
142 |
147 |
|||||
3/8 |
16 |
236 |
247 |
||||
24 |
259 |
271 |
|||||
7/16 |
14 |
376 |
393 |
||||
20 |
400 |
418 |
|||||
1/2 |
13 |
517 |
542 |
||||
20 |
541 |
565 |
|||||
Bolt Size
Inches or # |
Threads
Per Inch |
Standard Dry Torque in Inch-Pounds
|
|||||
304
Stainless Steel |
316
Stainless Steel |
||||||
9/16 |
12 |
682 |
713 |
||||
18 |
752 |
787 |
|||||
5/8 |
11 |
1110 |
1160 |
||||
18 |
1244 |
1301 |
|||||
3/4 |
10 |
1530 |
1582 |
||||
16 |
1490 |
1558 |
|||||
7/8 |
9 |
2328 |
2430 |
||||
14 |
2318 |
2420 |
|||||
1 |
8 |
3440 |
3595 |
||||
14 |
3110 |
3250 |
|||||
Bolt Size
Inches or # |
Threads
Per Inch |
Standard Dry Torque in Foot-Pounds
|
|||||
304
Stainless Steel |
316
Stainless Steel |
||||||
1 1/8 |
7 |
413 |
432 |
||||
12 |
390 |
408 |
|||||
1 1/4 |
7 |
523 |
546 |
||||
12 |
480 |
504 |
|||||
1 1/2 |
6 |
888 |
930 |
||||
12 |
703 |
732 |
|||||
Size Chart of AISI 304L Stainless Steel Nuts
Nut Size (mm) |
Diameter* (mm) |
Height (mm) |
||
|---|---|---|---|---|
Hex Nut |
Jam Nut |
Nylock Nut |
||
2 |
4 |
1.6 |
1.2 |
- |
2.5 |
5 |
2 |
1.6 |
- |
3 |
5.5 |
2.4 |
1.8 |
4 |
4 |
7 |
3.2 |
2.2 |
5 |
5 |
8 |
4 |
2.7 |
5 |
6 |
10 |
5 |
3.2 |
6 |
7 |
11 |
5.5 |
3.5 |
- |
8 |
13 |
6.5 |
4 |
8 |
10 |
17 |
8 |
5 |
10 |
12 |
19 |
10 |
6 |
12 |
14 |
22 |
11 |
7 |
14 |
16 |
24 |
13 |
8 |
16 |
18 |
27 |
15 |
9 |
18.5 |
20 |
30 |
16 |
10 |
20 |
* This is the diameter across the flats. It is also the size of wrench to use. |
||||
